Replica Chrome Oil Tank
Retail Price: $184.00
VT No
40-0429
OEM No: 62504-58
Replica chrome oil tank features side fill and wrap around type construction including seam-welded edges which show weld marks as on original tanks.
Replica chrome oil tank features side fill and wrap around type construction including seam-welded edges which show weld marks as on original tanks.
Tank has a rubber plug. Use with 1936-1957 battery rod tab supports. Tank measures 10-1/4" wide X 7-1/8" tall. Battery box measures 7-1/8" tall X 4-1/4" wide. Oil fitting is 20 TPI x 9/16. *NOTE: The battery compartment dimensions are 5" wide x 4-1/2" long x 7" tall.
Tank has a rubber plug. Use with 1936-1957 battery rod tab supports. Tank measures 10-1/4" wide X 7-1/8" tall. Battery box measures 7-1/8" tall X 4-1/4" wide. Oil fitting is 20 TPI x 9/16. *NOTE: The battery compartment dimensions are 5" wide x 4-1/2" long x 7" tall.
FITS | EL 1936-1940 UL 1941-1948 FL 1941-1964 |
|---|
| OEM No. | 62504-58 | |||
|---|---|---|---|---|
| UOM | 1 - EA | |||
| Measurements |
| |||
| Finish | Black | |||
| Manufacturer | Wyatt Gatling | |||
| Origin | Imported | |||
| Style | Wrap Around | |||
| 2025 Catalog Pages | 740 | |||
| Tech Note | Suggested to use with #42-9940 battery rod set. Suggested to use #8115-1, #8114-1, or #9504-1 timing plugs. Suggested to use with #2071-10 Chrome Chain Guard and Oil Tank Mount Kit. Suggested to use with #40-0877, WR Hex Barb Oil Line Fitting Set Zinc Plated | |||
| Other Notes |
|
