Linkert Snap Throttle Kit
Retail Price: $132.26
VT No
35-1713
Linkert snap throttle kit features a unique design revamped by Dan Henke and Rob Taylor from our Motor Shop. Kit is for use with M-74 carburetors. Includes shaft, throttle arm, cable end, shaft spring and cable bracket.
Linkert snap throttle kit features a unique design revamped by Dan Henke and Rob Taylor from our Motor Shop. Kit is for use with M-74 carburetors. Includes shaft, throttle arm, cable end, shaft spring and cable bracket.
Features a longer throttle shaft with provision for snap throttle spring. Includes the door, two screws, spring cotter pin, washer, shaft spring, arm and cable block. *NOTE: Shaft must be removed and replaced with this longer shaft. Top throttle arm and cable block are included. *NOTE: Installation requires bracket to secure the cable on the right side, which is included. The bracket is secured by top motor mount bolt. Bend end of spring as shown is photo.
Features a longer throttle shaft with provision for snap throttle spring. Includes the door, two screws, spring cotter pin, washer, shaft spring, arm and cable block. *NOTE: Shaft must be removed and replaced with this longer shaft. Top throttle arm and cable block are included. *NOTE: Installation requires bracket to secure the cable on the right side, which is included. The bracket is secured by top motor mount bolt. Bend end of spring as shown is photo.
FITS | FL 1941-1965 EL 1936-1965 |
|---|
| UOM | 1 - KIT |
|---|---|
| Manufacturer | V-Twin |
| Origin | Imported |
| Replacement Items | 35-1711 - Linkert Snap Throttle Shaft Return Spring 35-1712 - Linkert Snap Throttle Shaft 35-0340 - Linkert Cable Bracket Kit Zinc Plated |
| Tech Note | Required to use with #35-0340 Linkert Cable Bracket Kit ZincPlated. |
