"L" Series Carburetor Body
Retail Price: $310.72
VT No
35-0977
L" Series 1-7/8" bore carburetor body is cast aluminum.
L" Series 1-7/8" bore carburetor body is cast aluminum.
Body casting is an exact replica of the "L" series Linkert MGL gas carburetor design produced by S&S in 1980-81. Body has 1-7/8" bore and will accept original or replacement parts. Accepts a 4" throttle shaft. Features a built-in choke mechanism and side mounted float bowl. Air cleaner mounting pattern is the same as on stock Tillotson, Bendix, Keihin butterfly type carburetors. Changeable intermediate air bleed screws into boss adjacent to intermediate jet on the top of the carburetor. Intermediate jet goes through ventruri from top of carburetor down into main discharge tube. #66 main jet and #33 intermediate jet are recommended. For use on an S&S manifold. Manifold is not included.
Body casting is an exact replica of the "L" series Linkert MGL gas carburetor design produced by S&S in 1980-81. Body has 1-7/8" bore and will accept original or replacement parts. Accepts a 4" throttle shaft. Features a built-in choke mechanism and side mounted float bowl. Air cleaner mounting pattern is the same as on stock Tillotson, Bendix, Keihin butterfly type carburetors. Changeable intermediate air bleed screws into boss adjacent to intermediate jet on the top of the carburetor. Intermediate jet goes through ventruri from top of carburetor down into main discharge tube. #66 main jet and #33 intermediate jet are recommended. For use on an S&S manifold. Manifold is not included.
FITS | Replacement application for S&S "L" series carburetor |
|---|
| UOM | 1 - EA |
|---|---|
| Manufacturer | V-Twin |
| Origin | Imported |
| 2025 Catalog Pages | 716 |
| Tech Note | Suggested to use with #35-0288 Intermediate Fixed Air Jet Assortment. Suggested to use with #35-0303 "L" Series Carburetor Intermediate Jet. Suggested to use with #35-1673 "L" Series Carburetor Choke Door Assembly. |
