18" Inline Spring Fork Assembly Black
Retail Price: $1,331.75
VT No
49-2400
Stock replica Spring Fork assembly accepts all original style components and accessories for a detailed restoration look. The 45 rockers are mounted in board of the fork legs and accepts a 3/8" diameter axle.
Stock replica Spring Fork assembly accepts all original style components and accessories for a detailed restoration look. The 45 rockers are mounted in board of the fork legs and accepts a 3/8" diameter axle.
Assembly includes inner and outer springs, front and rear legs, inside rockers for a 3/8" axle, spring rod with bushings and internal brake wheel with all studs and bushings. Top clamp, neck races, and cone nut are not included. Some assembly may be required. 1" tubes on rear legs are tapped 3/4"-16 to accept threaded riser bushing set, with this installed the builder can use a triple tree without ears and choice of post riser set. The stem is 7/8". The distance between the rockers measure 6.5".Assembly is a product of 14 separate processes: Tubing, Hydraulic Swage Press, Investment Casting, Forging, Flattening Press, Robotic Welding, Brazing, Polish, Chrome, Paint, Spring Winder, Machine Shop, Drill Shop and Packaging. *Note: UPS may consider this part as packaged "oversize" for shipment, as compared to the actual weight, which will result in higher shipping costs. *NOTE: We measure from the top of the rear leg (tube), to the front axle center line.
Assembly includes inner and outer springs, front and rear legs, inside rockers for a 3/8" axle, spring rod with bushings and internal brake wheel with all studs and bushings. Top clamp, neck races, and cone nut are not included. Some assembly may be required. 1" tubes on rear legs are tapped 3/4"-16 to accept threaded riser bushing set, with this installed the builder can use a triple tree without ears and choice of post riser set. The stem is 7/8". The distance between the rockers measure 6.5".Assembly is a product of 14 separate processes: Tubing, Hydraulic Swage Press, Investment Casting, Forging, Flattening Press, Robotic Welding, Brazing, Polish, Chrome, Paint, Spring Winder, Machine Shop, Drill Shop and Packaging. *Note: UPS may consider this part as packaged "oversize" for shipment, as compared to the actual weight, which will result in higher shipping costs. *NOTE: We measure from the top of the rear leg (tube), to the front axle center line.
FITS | WL 1936-1952 |
|---|
| UOM | 1 - EA | ||
|---|---|---|---|
| Measurements |
| ||
| Manufacturer | V-Twin | ||
| Origin | Imported | ||
| 2025 Catalog Pages | 779 | ||
| Replacement Items | 49-1762 - 18" Spring Fork Assembly Black 37-0862 - Black Hex Nuts 7/16"-20 49-0528 - Spring Fork Rocker Kit | ||
| Tech Note | Suggested to use with #49-1963 WL Front Axle Black. *NOTE: 45" Spring Fork rockers are mounted to the inside of the fork and utilize a 3/8" axle. 45" Servi-Cars, 1947-1957,use Big Twin rockers on the outside of the fork. How we measure Spring Forks. NOTE: Measurement is from the triple tree where stem and lower bearing sits, to the axle position. This is the effective length, as it is the legnth from the lower bearing cup on the frame to axle. Installer can slide a pipe or solid bar thru the bearing cups and measure the length that may be needed for the desired frame height. This Spring Fork assembly accepts a 3/4" axle for custom applications. As rockers are not offset (as on replica Spring Forks). 1" stem utilized tapered bearings for ease of installation. |
