Replica Magneto Driveshaft Assembly
Retail Price: $148.47
VT No
32-1346
WARNING: Cancer and/or Reproductive Harm - www.P65Warnings.ca.gov/Replica magneto driveshaft assembly comes assembled with hex top, gear and cast iron base with raw finish.
Replica magneto driveshaft assembly comes assembled with hex top, gear and cast iron base with raw finish.
Cast iron base with pre-installed bushings features a raw unplated finish.Pieces can be cadium or zinc.Drive ring and center hub are zinc plated. Assembly includes spiral to drive tachometer as original. Drive gear must be installed with a drive gear pin, when installing the pin press in and grind off excess length. Base will also accept a hex drive magneto unit, cable driven gear and 34-1/4" tachometer cable. Tachometer drive gear and cable available separately. Order magneto head separately. This is the real deal Sportster advance mechanism as the factory supplied from 1965-1970 on the XLCH models, Get Real! All components as original.
Cast iron base with pre-installed bushings features a raw unplated finish.Pieces can be cadium or zinc.Drive ring and center hub are zinc plated. Assembly includes spiral to drive tachometer as original. Drive gear must be installed with a drive gear pin, when installing the pin press in and grind off excess length. Base will also accept a hex drive magneto unit, cable driven gear and 34-1/4" tachometer cable. Tachometer drive gear and cable available separately. Order magneto head separately. This is the real deal Sportster advance mechanism as the factory supplied from 1965-1970 on the XLCH models, Get Real! All components as original.
FITS | K 1952-1956 XL 1957-1970 |
|---|
| UOM | 1 - KIT |
|---|---|
| Manufacturer | Volt Tech |
| Origin | Imported |
| 2025 Catalog Pages | 1303 |
| Replacement Items | 32-0823 - Magneto Base 32-0515 - Magneto Base Adapter Plate 32-0516 - Zinc Plated Magneto Advance Lower Adapter Plate 32-0584 - Magneto Drive Shaft and Gear Kit |
| Tech Note | Suggested to use with #32-1298 Magneto Assembly without Shaft. Suggested to use with #37-1027 Contact Screw Washer and #13-0168 Adjusting Screw Spring with this Round Outer Rotation Ring. Suggested to use with #36-0514 Magneto Tachometer Cable Driven Gear. Suggested to use with #36-0513 Black Magneto Tachometer Cable. |
